The F2480NBGI8 is a 400MHz to 3000MHz RF analog variable gain amplifier (AVGA) for receivers, transmitters and other applications. An amplifier or voltage variable attenuator (VVA) can be configured as the first stage in the cascade. The F2480 RF AVGA offers a typical maximum cascade gain of 12dB (without attenuation), a 4.3dB noise figure (with the amplifier as the first stage), and 36dB gain adjustment, and is designed to be powered by a single +5V supply.

Technical parameter

Frequency: 400MHz ~ 3GHz

P1dB: 20.9dBm

Gain: 14.4dB

Noise factor: 5dB

Rf type: -

Voltage - Power supply: 4.75V ~ 5.25V

Current - Power supply: 121mA

Test frequency: 400MHz ~ 2.7GHz

Mounting type: Surface mount type

Package/housing: 32-WFQFN bare pad

Supplier Package: 32-VFQFPN (5x5)

Basic product number: F2480
