The NCP170AMX280TBG series of CMOS low dropout regulators are designed specifically for portable battery-powered applications which require ultra-low quiescent current. The ultra-low consumption of typ. 500 nA ensures long battery life and dynamic transient boost feature improves device transient response for wireless communication applications. The device is available in small 1 × 1 mm XDFN4, SOT-563 and TSOP-5 packages.

Features

• Operating Input Voltage Range: 2.2 V to 5.5 V

• Output Voltage Range: 1.2 V to 3.6 V (0.1 V Steps)

• Ultra-Low Quiescent Current Typ. 0.5 A

• Low Dropout: 170 mV Typ. at 150 mA

• High Output Voltage Accuracy ±1%

• Stable with Ceramic Capacitors 1 F

• Over-Current Protection

• Thermal Shutdown Protection

• NCP170A for Active Discharge Option

• Available in Small 1 × 1 mm XDFN4, SOT−563 and TSOP-5 Packages

• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant

Typical Applications

• Battery Powered Equipments

• Portable Communication Equipments

• Cameras, Image Sensors and Camcorders
