Trade Name:ADA4841-2YRZ
Data Manual:ADA4841-2YRZ.pdf
Brand:ADI
Particular Year:23+
Package:SOIC-8
Delivery Date:New and Original
Stock: 8000pcs
The ADA4841-2YRZ are single-gain stabilised, low-noise, low-distortion, rail-to-rail output amplifiers with a maximum quiescent current of 1.5 mA. These amplifiers not only consume low power, but also offer low broadband voltage noise performance of 2.1 nV/√Hz, current noise of 1.4 pA/√Hz, and excellent -105 dBc spurious-free dynamic range (SFDR) at 100 kHz. SFDR) at 100 kHz. To maintain a low-noise environment at even lower frequencies, the amplifier has low 1/f noise of 7 nV/√Hz and 13 pA/√Hz at 10 Hz.
The ADA4841-2YRZ has an output swing of less than 50 mV per supply rail and an input common-mode voltage range that extends to negative supply voltages, allowing capacitive loads of up to 10 pF to be driven with a minimum peak.
Product Features
Low power consumption: 1.1 mA per amplifier
Low broadband noise
2.1 nV/√Hz
1.4 pA/√Hz
Low 1/f noise
7 nV/√Hz (10 Hz)
13 pA/√Hz (10 Hz)
Low distortion: -105 dBc (100 kHz), VO = 2 V p-p
High Speed
-3 dB bandwidth: 80 MHz (G = +1)
Slew rate: 12 V/μs
0.1% build-up time: 175 ns
Low offset voltage: 0.3 mV (max)
Rail-to-rail output
Shutdown mode
Wide supply voltage range: 2.7 V to 12 V
Applications
Low-power, low-noise signal processing
Battery-powered instrumentation
16-bit PulSAR® ADC devices
