TLF35584QVVS1 is a high efficient Functional Safety Power Management Integrated Circuit.

Features

High efficient power management integrated circuit (PMIC)

Serial step up and step down pre regulator for wide input voltage rangefrom 3.0 to 40 V with full performance and low over all power loss

Low drop post regulator 5.0 V/200 mA for communication supply

Low drop post regulator 5.0 V/600 mA or 3.3 V/600 mA for µC supply

Voltage reference 5.0 V ±1% for ADC supply, 150 mA current capability

Two trackers for sensor supply following voltage reference 150 mA currentcapability each

Standby regulator 5.0 V/10 mA or 3.3 V/10 mA

Provides enable, sync out signal and voltage monitoring for an optionalexternal post regulator for core supply

Independent voltage monitoring block and error pin monitoring

Configurable window and functional watchdog

Safe State Control with two safe state signals with programmable delay

16-bit SPI, interrupt and reset function

Potential applications

Electric Power Steering

Battery Management

Inverter

Transmission

Engine Management

Domain Control
