TPS37F010122DSKR is a wide input range and low quiescent current window supervisors for fast detection of overvoltage (OV) and undervoltage (UV) conditions.

Features

Wide supply voltage range: 2.7 V to 65 V

SENSE and RESET pins are 65 V graded

Low quiescent current: 1 µA (typical)

Flexible and wide voltage threshold options

2.7 V to 36 V (1.5% maximum accuracy)

800 mV option (1% maximum accuracy)

Built-in hysteresis (VHYS)

Percentage options: 2% to 13% (1% steps)

Fixed options: VTH < 8 V = 0.5 V, 1 V, 1.5 V,2 V, 2.5 V

Programmable reset time delay– 10 nF = 12.8 ms, 10 μF = 12.8 s

Programmable sense time delay– 10 nF = 1.28 ms, 10 μF = 1.28 s

Manual Reset (MR) feature

Output topology: Open-Drain or Push-Pull

Applications

Analog input module

CPU (PLC controller)

Servo drive control module

Servo drive power stage module

Servo drive functional safety module

HVAC valve and actuator control
