The Infineon IPB200N25N3G 250V OptiMOS™ product features advanced performance benchmark technology and is perfectly suited for asynchronous rectification in 48V systems, DC-DC converters, Uninterruptible Power Supplies (UPS) and DC motor drive inverters.

Product Attributes

Manufacturer: Infineon

Product Category: MOSFETs

Technology: Si

Mounting Style: SMD/SMT

Package / Case: TO-263-3

Transistor polarity: N-Channel

Number of channels: 1 Channel

Vds-Drain-source breakdown voltage: 250 V

Id-Continuous drain current: 64 A

Rds On-drain on-resistance: 17.5 mOhms

Vgs - gate-source voltage: - 20 V, + 20 V

Vgs th - gate-source threshold voltage: 2 V

Qg-gate charge: 86 nC

Minimum operating temperature: - 55 C

Maximum operating temperature: + 175 C

Pd-power dissipation: 300 W

Channel mode: Enhancement

Trademark: OptiMOS

Series: OptiMOS 3

Configuration: Single

Fall Time: 12 ns

Forward transconductance - min: 61 S

Height: 4.4 mm

Length: 10 mm

Rise Time: 20 ns

Transistor Type: 1 N-Channel

Type: OptiMOS 3 Power-Transistor

Typical Off Delay Time: 45 ns

Typical turn-on delay time: 18 ns

Product Application

Synchronous rectification for AC-DC SMPS

Motor Control for 48V-110V Systems

Isolated DC-DC converters

110V AC network lighting

HID lamps

Class D Audio Amplifiers

Uninterruptible Power Supply (UPS)
