Shenzhen Mingjiada Electronics Co., Ltd. presents AMD Ryzen AI Processor 100-000001324 (FP7r2) AMD Ryzen™ 5 8640U, brand new and original, with advantageous price, welcome to enquire!

Device Overview: 100-000001324 (FP7r2)

The AMD Ryzen 5 8640U is a 6-core mobile processor that is part of the Ryzen 5 family, featuring the Zen 4 (Eagle Point) architecture and Socket FP8. The processor doubles the number of cores to 12 threads thanks to AMD Simultaneous Multithreading (SMT) technology. The Ryzen 5 8640U has 16 MB of L3 cache and operates at 3.5 GHz by default, but can be boosted up to 4.9 GHz depending on the workload.AMD built the Ryzen 5 8640U on a 4nm production process using 25,000,000 transistors. The silicon for the chip is not manufactured at AMD, but at TSMC's foundry.The multiplier frequency of the Ryzen 5 8640U is locked, which limits its overclocking capabilities.

The Ryzen 5 8640U has a TDP of 28 W, which is very low power consumption.The AMD processor supports DDR5 memory with dual-channel interface. The maximum officially supported memory speed is 5600 MT/s, but higher speeds can be achieved with overclocking (and the right memory modules). To communicate with other components in the computer, the Ryzen 5 8640U uses a PCI-Express Gen 4 connection. This processor uses the Radeon 760M integrated graphics solution.

The Ryzen 5 8640U offers hardware virtualisation to greatly improve virtual machine performance. Programs that use Advanced Vector Extensions (AVX) can run on this processor, improving the performance of computationally intensive applications. In addition to AVX, AMD has added support for the latest AVX2 and AVX-512 instructions.

General Specifications (100-000001324)

Name: AMD Ryzen™ 5 8640U

Product Family: Ryzen

Series: Ryzen 8000 Series

Form Factor: Laptop , Desktop

AMD PRO Technology: No

Consumer Use: Yes

Regional Availability: Global

Form Factor: Hawk Point

Architecture: Zen 4

CPU Cores: 6

Multi-threaded (SMT): Yes

Number of Threads: 12

Maximum Accelerated Clock Frequency: Up to 4.9 GHz

Base clock frequency: 3.5 GHz

L2 Cache: 6 MB

L3 Cache: 16 MB

Default Thermal Design Power (TDP): 28W

AMD Configurable Thermal Design Power (cTDP): 15-30W

Processor process for CPU cores: TSMC 4nm FinFET

CPU Compute Chip (CCD) size: 178mm²

Package Chip Count: 1

Unclocked: No

AMD EXPO™ Memory Overclocking Technology: No

Precision Boost (PBO): No

Curve Optimiser Voltage Offset: No

CPU Platform: FP7r2

Supported Extensions: AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64

Maximum operating temperature (Tjmax): 100°C

*Supported OS: Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
