ACPL-064L-560E Broadcom, high-speed optical coupler 10MBd

ACPL-064L-560E Broadcom, high-speed optical coupler 10MBd

Source:our siteTime:2024-06-20Views:

The ACPL-064L-560E high-speed optical coupler is ideal for communication interfaces, microprocessor system interfaces, and digital isolation of ADCs and Dacs.

Overview

The Broadcom ACPL-064L digital CMOS optocoupler is an ultra-low power, 10MBd device that integrates an AIGaAs LED and an integrated high-gain photodetector. The forward LED current of the ACPL-064L is as low as 1.6 MA, which means that most microprocessors can drive leds directly. Broadcom digital CMOS optical couplers have built-in Faraday shielding to guarantee common mode transient immunity of 20kV/ s.


The ACPL-064L achieves maximum AC and DC circuit isolation while maintaining TTL/CMOS compatibility. Broadcom digital CMOS optocoupler pressure swing rate control designed to control rise and fall times over a wide range of load capacitors. The ACPL-064L is ideal for communication interfaces, microprocessor system interfaces, and digital isolation of ADCs and Dacs.


Features

1.3ma/ channel maximum ultra-low IDD current

1.6mA Low input current

Built-in pressure swing rate control output

The minimum common mode rejection (CMR) at VCM = 1000V is 20kV/μs

10MBd minimum speed

-40°C to +105°C ensures AC and DC performance over a wide temperature range

Wide package options for SO-5, SO-8, stretched SO-6 and stretched SO-8

Safety certification

UL 1577 certification - ACPL-064 l/M61L 1 minute 3750Vrms, ACPL-W61L/K64L 1 minute 5000Vrms

CSA approval

IEC/EN/DIN EN 60747-5-5 certification for enhanced insulation

Comply with RoHS standards


Applications

Communication interface :RS485, CANBus and I2C

Microprocessor system interface

Digital isolation of A/D and A/D converters


Functional block diagram


Mingjiada Electronics Supply/Recovery ACPL-064L-560E Broadcom, High Speed Optocoupler 10 MBd.


Supply [Realtek] Gigabit Switch Controller, Wireless LAN IC, GNSS Receiver, Bluetooth Audio SoC Return to
