Mingjiada Electronics supplies MEC1701Q-C2-SZ: Notebook Computer Keyboard and Embedded Controller IC

Product Description

The MEC1701Q-C2-SZ is a high-performance embedded controller (EC) specifically designed for notebook computer keyboard control, system management, and low-power peripheral interfaces. This chip is manufactured by Microchip and features a 32-bit ARM® Cortex®-M4 core, integrating keyboard matrix scanning, power management, GPIO expansion, and secure boot functionality. It is widely used in laptops, Ultrabooks, and industrial embedded systems.

MEC1701Q-C2-SZ Features

✅ Keyboard Control: Supports 16×8 matrix scanning, expandable to 104 keys, with anti-vibration and fast response capabilities.

✅ Low-Power Management: Supports ACPI (Advanced Configuration and Power Interface) and S0ix modern standby mode to optimise battery life.

✅ Rich Peripheral Interfaces:

8×UART (for BIOS debugging, sensor communication)

2×I²C, 2×SPI (connecting touchpads, TPM security chips, etc.)

32 programmable GPIOs (expanding system control functionality).

✅ Secure Boot: Supports hardware encryption (AES-128/256, SHA-1/256) to prevent firmware tampering.

✅ Industrial-grade reliability: Operating temperature 0°C to 70°C, meets stringent environmental requirements.

MEC1701Q-C2-SZ Specifications

Core processor: ARM® Cortex®-M4F

Maximum operating frequency: 48MHz

Host interfaces: eSPI, LPC, I2C

Keyboard scan matrix: 18x8

RAM Size: 32KB (Data RAM) + 480KB (Code + Data)

GPIO Count: 148

LED Interface: 4 (Breathing/Flashing LEDs)

Operating Temperature Range: 0°C to 70°C

ADC: 8

BC Link: 2

ACPI Interface: 5

Package: 144-WFBGA (9x9)

Supply Voltage: 1.71V to 3.465V

MEC1701Q-C2-SZ Applications

Laptop Keyboard Control (Supports Backlight Adjustment, Fn Shortcut Keys)

Ultrabook Power Management (S0ix Low-Power Mode)

Industrial Embedded HMI (Human-Machine Interface, Keypad Panel)

Server BMC (Baseboard Management Controller) (remote monitoring and management)
