ME2005602311011 is 0.60mm, Mini Cool Edge Card Edge Connectors——Storage and Server connector,EDSFF, 56 signal pins, 1x1, Gen 4, Press-fit, Orthogonal.

Specification Of ME2005602311011

Series:Mini Cool Edge 0.60mm

Gender:Female

Number of Positions/Bay/Row:28

Number of Positions:56

Card Thickness:0.062" (1.57mm)

Number of Rows:2

Pitch:0.024" (0.60mm)

Read Out:Dual

Mounting Type:Through Hole, Right Angle

Termination:Press-Fit

Contact Material:Copper Alloy

Contact Finish:Gold

Contact Finish Thickness:30.0µin (0.76µm)

Contact Type:Cantilever

Color:Natural

Operating Temperature:-55°C ~ 105°C

Material - Insulation:Thermoplastic

Features Of ME2005602311011

Signal pin pitch at 0.60mm with current rating of 1.1A, up to 12 pins for power application

Signal pins options from 56, 84, 140, 168, 280

Customization of pin count upon request

Small form factor

Discrete pin design

Supports 1.6mm thick mating board, 1.97mm, 2.36mm option upon request

Hybrid & power individual options from 4C-HP, 4 power pins and 2 power pins available

Applications Of ME2005602311011

Communications

Baseband

Commercial Systems

Networking

Radio Units

Data

High-end Computing System

Server and Storage Systems
