Trade Name:Card Edge Connectors
Brand:Amphenol
Particular Year:21+
Package:24POS
Delivery Date:New and Original
Stock: 1000pcs
10121505-320424DLF is a high-power card edge (HPCE®) connector launched by Amphenol, featuring a 60-position (24+36 power/signal) dual-sided layout, suitable for high-power applications such as servers, storage devices, industrial control, and communication equipment.
Core Features
High Power Density Design
60-pin (24 power + 36 signal) configuration supports mixed configurations of high-current transmission and high-speed signals.
Dual-sided layout optimises PCB space utilisation.
High Reliability Connection
Contact material: copper alloy with gold plating or GXT™ coating, reducing contact resistance and enhancing oxidation resistance.
Termination method: Press-fit, ensuring secure PCB installation.
Industrial-grade durability
Operating temperature: -55°C to +105°C, suitable for harsh environments.
Black plastic housing with dust-proof and vibration-resistant properties.
Compatibility
Non-specific card type, compatible with various PCB thicknesses (standard 1.57mm).
Female design, compatible with standard card edge slots.
Product attributes
Product type: Standard card edge connector
Number of positions: 24 positions
Pitch: 2.54 mm
Installation style: Press Fit
Installation angle: Vertical
Series: PwrBlade
Housing material: Thermoplastic (TP)
Insulation Resistance: 500 MOhms, 5 GOhms
Maximum Operating Temperature: +105°C
Minimum Operating Temperature: -55°C
Trademark Name: PwrBlade
Voltage Rating: 17 V, 548 V
Model
Brand
Package
Quantity
Describe
Samtec
80POS
2000
0.80 mm Generate™ High-Speed Edge Card Connector, Right-Angle
