DPS-1300AB-21 AC-DC CRPS Front-End power supply accepts a wide range 90 – 264 VAC input and provides a main 12 V output plus a 12V standby output. Rated between 550 and 1300 watts, it has a high peak efficiency of 94%. Housed in a 1U high, 2.9inch wide rack mount enclosure, the power supply is primarily designed for enterprise servers and similar applications.

Specifications Of DPS-1300AB-21

Number of Outputs:1

Voltage - Input:90 ~ 264 VAC

Voltage - Output 1:12V

Current - Output 1:108 A

Power (Watts):1296W

Applications:ITE (Commercial)

Efficiency:94%

Operating Temperature:0°C ~ 55°C

Features:PFC, PMBus™, Remote On/Off, Remote Sense, Standby Output, Universal Input

Mounting Type:Rack Mount

Size / Dimension:7.28" L x 2.89" W x 1.57" H (185.0mm x 73.5mm x 40.0mm)

Approval Agency:BIS, BSMI, CB, CCC, KC, KCC, TUV, UL

Features Of DPS-1300AB-21

Meets 80 PLUS Platinum Efficiency

12V Main Output

12V Standby Output

1U Height

Redundant (N+1) Operation

Power Factor Correction

Overvoltage, Overcurrent, Overtemperature Protection

Remote on/off Control

Remote Sense

Internal Cooling Fan (variable speed)

PMBus 1.2 Support

RoHS Compliant
