AA04S1200A is a 4W single-output AC/DC power module manufactured by Delta Electronics, suitable for PCB mounting. Featuring an ultra-compact design, this module is ideal for commercial and industrial electronic equipment.

AA04S1200A Product Specifications

Manufacturer:    Delta Electronics

Product Type:    AC/DC Power Module

Output Power:    4 W

Input Voltage: 85 VAC to 264 VAC, 120 VDC to 370 VDC

Number of Outputs:    1 Output

Output Voltage—Channel 1:    12 V

Output Current—Channel 1:    333 mA

Mounting Style:    Through Hole

Length:    27 mm

Width:    36.5 mm

Height:    17.1 mm

Industrial:    Medical, Industrial

Series:    AA04

Encapsulation Type:    Encapsulated

Input Frequency:    47 Hz to 440 Hz

Insulation Voltage:    3 kV

Load Regulation:    Regulated

Maximum Operating Temperature:    +60°C

Minimum Operating Temperature:    -25°C

Open Frame/Enclosed:    Enclosed

AA04S1200A Features

Ultra-compact design: Suitable for PCB mounting.

Overload and overvoltage protection: Ensures equipment safety.

Electromagnetic interference (EMI): Complies with EN55022, Class B standard.

Electromagnetic compatibility (EMS): Complies with EN61000-4 standard.

Universal input voltage range: 85-264 VAC, 47-440 Hz.

High efficiency: Typical efficiency of 76%.

Safety certification: UL/IEC/EN 60950-1 certified, CE marked.

3kVAC isolation: Complies with Protection Level II.

Lead-free, RoHS compliant.

3-year product warranty.

AA04S1200A Applications

Commercial and industrial electronic equipment: Suitable for devices requiring efficient, compact power solutions.

Information technology equipment (ITE).
