The A89301GESSR is a three-phase sensorless brushless DC (BLDC) motor driver operating within a voltage range of 5.5 to 50V.

This device fully integrates a field-oriented control (FOC) algorithm to achieve optimum efficiency and acoustic noise performance. It optimises motor start-up performance during standstill, coasting, and even reverse coasting conditions.

Motor speed is controllable via analogue signal, PWM, or clock signal inputs. Optional closed-loop speed control is supported, with the speed-to-clock frequency ratio being programmable.

A simplified I²C interface facilitates setting the motor's rated voltage, rated current, rated speed, resistance value, and start-up curve. This interface also supports switch control, speed adjustment, and speed readout functions.

The A89301GESSR is housed in a 24-pin 4mm × 4mm QFN package with a exposed pad (suffix ES). The package is lead-free and utilises a 100% matt tin-plated lead frame.

A89301GESSR Features and Benefits

• Encoderless, sensorless field-oriented control (FOC)

• I²C interface for speed control and status readout

• Ultra-quiet low-speed operation

• Proprietary non-reversing rapid start

• Soft start/soft stop (SOSO) for silent operation

• Analogue/PWM/clock mode speed control

• Closed-loop speed control

• Configurable current limit

• Windmill start mode

• Lock detection

• Short-circuit protection (OCP)

• Brake and direction inputs

• Adjustable gate drive

A89301GESSR Applications

• Ceiling fans

• Pedestal fans

• Bathroom extractor fans

• Domestic appliance fans and pumps
