The NUD4700SNT1G is an electronic shunt that provides current bypassing in the event of an open-circuit fault in a single LED. LEDs themselves are relatively vulnerable to transient and surge conditions. In many applications, the high reliability of LED lighting must be maintained, such as in headlights, lighthouses, bridges, aircraft, runways, etc. In such cases, adding the low-cost NUD4700SNT1G ensures that the entire LED string does not go dark due to a single LED failure. The NUD4700SNT1G is also suitable for other loads requiring circuit continuity. The device is designed for use with 1 W LEDs (rated at 350 mA @ 3 V).

Features of the NUD4700SNT1G

• Simple two-port device

• Automatically resets if the LED self-repairs or is replaced

• On-state voltage typically 1 V

• Off-state current less than 250 A

• Available in white packaging

• SZ prefix (black packaging only) is suitable for automotive and other applications requiring unique field and control change requirements; compliant with AEC-Q101 standards and supports PPAP

• These devices are lead-free, halogen-free/BFR-free, and compliant with RoHS standards

NUD4700SNT1G Parameters

Breakdown voltage:    7.5 V

On-state voltage:    1.2 V

Rated repetitive off-state voltage VDRM:    10 V

Package/housing:    PowerMITE-2

Circuit type:    Shunt

Maximum holding current Ih:    12 mA

Maximum operating temperature:    +150°C

Minimum operating temperature:    -40°C

Mounting style:    SMD/SMT

Off-state leakage current (under VDRM IDRM):    1.3 A

On-state RMS current - It RMS:    376 mA

Typical applications for NUD4700SNT1G

• LED applications where preventive maintenance is impractical

• LED headlights

• LED applications with high reliability requirements

• Short-circuit protection under open-circuit conditions

• Overvoltage protection for sensitive circuits
