Trade Name:Voltage Reference
Brand:ADI
Particular Year:24+
Package:SOIC-8
Delivery Date:New and Original
Stock: 5000pcs
ADR421ARZ: Voltage Reference IC — Ultra-Precision, Low-Noise, 2.5V XFET® Voltage Reference Source, SOIC-8
The ADR421ARZ is an ultra-precise, second-generation externally ion-implanted field-effect transistor (XFET) reference voltage source featuring low noise, high accuracy, and excellent long-term stability, packaged in an SOIC-8 package.
The ADR421ARZ offers outstanding noise performance, stability, and accuracy, making it ideal for precision conversion applications such as fibre-optic networks and medical equipment. Additionally, its adjustment pin allows the output voltage to be adjusted within ±0.5% without affecting other performance characteristics.
ADR421ARZ Specifications:
Series: XFET®
Output Type: Fixed
Voltage - Output (Minimum/Fixed): 2.5V
Current - Output: 10 mA
Tolerance: ±0.12%
Temperature Coefficient: 10 ppm/°C
Noise - 0.1 Hz to 10 Hz: 1.75 µVp-p
Voltage - Input: 4.5 V to 18 V
Current - Supply: 600 µA
Operating Temperature: -40°C to 125°C (TA)
Mounting Type: Surface Mount
Package/housing: 8-SOIC (0.154", 3.90mm wide)
ADR421ARZ Product Features:
Low noise (0.1 Hz to 10 Hz)
ADR421: 1.75 μV peak-to-peak
Low temperature coefficient: 3 ppm/°C
Long-term stability: 50 ppm/1000 hours
Load regulation: 70 ppm/mA
Voltage regulation: 35 ppm/V
Low hysteresis: 40 ppm (typical)
Wide operating voltage range: 4.5 V to 18 V
Quiescent current: 0.5 mA (maximum)
High output current: 10 mA
Wide temperature range: −40°C to +125°C
