The IMX3102-Y1B000NCG8 is a 2:1 bus multiplexer launched by Renesas, specifically designed for I3C and I2C buses, supporting multi-master device control and high-speed data transmission. It supports 2:1 bus multiplexing and can flexibly switch the control of the master device ‌, with a maximum transmission rate of 12.5MHz.

Technical characteristics

2:1 bus multiplexer

Dual-wire programmable I²C or I³C bus serial interface

A single device load on the host bus

A transmission rate up to 12.5MHz

Single 1.8V power input

1.0V VLDO output for VIO pin

Supports 1.0V, 1.1V and 1.2V push-pull IO levels

Supports open drain IO levels of 1.0V, 1.1V, 1.2V, 1.8V, 2.5V and 3.3V

Integrated temperature sensor; 0.5 °C accuracy and 0.25 °C resolution

Packet Error Checking (PEC) function, parity error checking function

Bus reset function

In-band Interruption (IBI

Programmable I²C and I³C bus addressing schemes

Temperature: Industrial range is -40 °C to 85 °C

Application field

The IMX3102-Y1B000NCG8 device is mainly used in fields such as data centers, servers, industrial automation, and communication equipment, addressing the demands of multiple master devices, complex cabling, and high-speed transmission.
