Trade Name:CPLD (Complex Programmable Logic Device)
Data Manual:
5M240ZT144C5N.pdf
Brand:Intel
Particular Year:23+
Package:TQFP-144
Delivery Date:New and Original
Stock: 5000pcs
The 5M240ZT144C5N is the MAX V series low cost and low power CPLD offering greater density and I/O per footprint. The MAX V device has on-chip flash memory, internal oscillator, and memory functions. Compared to other CPLDS, MAX V CPLDS reduce the total power consumption by 50% and require only one power supply, which can help you meet low power design requirements.
specification
Programmable type: Programmable within the system
Delay tpd(1) Maximum value: 7.5ns
Power supply voltage - Internal: 1.71V to 1.89V
Logical elements/blocks: 240
Number of macro cells: 192
Number of I/ OS: 114
Operating temperature: 0°C ~ 85°C (TJ)
Mounting type: surface mount type
Package/case: 144-TQFP (20x20)
Model
Brand
Package
Quantity
Describe
Intel
FBGA-100
10000
CPLD - Complex Programmable Logic Device IC CPLD 192MC 4.7NS 100FBGA
Intel
TQFP-100
3000
CPLD - Complex Programmable Logic Device IC CPLD 64MC 7.5NS 100TQFP
Intel
100-TFBGA
1000
CPLD - Complex Programmable Logic Devices, 128MC 7.5NS 100-MBGA (6x6)
Altera
FBGA-256
1000
Complex Programmable Logic Device IC CPLD 980MC 6.2NS 256FBGA (17x17)
Altera
TQFP-144
1000
Complex Programmable logic device IC CPLD 980MC 6.2NS 144TQFP (20x20)
Altera
TQFP-144
1000
Complex Programmable logic device IC CPLD 980MC 6.2NS 144TQFP (20x20)
A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.
A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.
A: at present, our self-employed brands TI，ST，ADI，NXP，LATTICE，CYPRESS，INFINEON，XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.
A: You can inquire through the website, or by phone and email.
A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.
A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
