For picture reference, please see the specifications
< >

Commodity Model:EPM570T144I5N

Trade Name:CPLD - Complex Programmable Logic Device

Brand:Intel

Particular Year:21+

Package:TQFP-144

Delivery Date:New and Original

Stock: 10000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Intel
Model
EPM570T144I5N
Package
TQFP-144
Describe
CPLD - Complex Programmable Logic Device IC CPLD 440MC 5.4NS 144TQFP

Product Description

The EPM570T144I5N is a high-performance complex programmable logic device (CPLD) introduced by Intel, part of the MAX® II series, packaged in a 144-pin TQFP (20×20mm). The chip is based on a Flash memory architecture, featuring 570 logic elements (LE) and 440 macrocells, and supports in-system programming (ISP), making it suitable for applications in communications, industrial control, embedded systems, and other fields.


EPM570T144I5N Key Features

High-performance logic processing: Maximum clock frequency of 304MHz and latency of 5.4ns, ideal for high-speed data processing.

570 logic elements (LEs), each containing 4-input LUTs and flip-flops, supporting complex logic designs.

Rich I/O interfaces: 116 I/O pins supporting multiple voltage standards including LVCMOS, LVTTL, PCI, and LVDS.

Low-power design: Operating voltage range of 2.5V to 3.3V, static power consumption of 470mW, and dynamic power consumption of 1.4W, suitable for energy-efficient applications.

Flexible storage resources: 8192-bit user flash memory (UFM) for storing configuration data or small programs.

Industrial-grade reliability: Operating temperature range of -40°C to +100°C, compliant with RoHS standards, suitable for harsh environments.


EPM570T144I5N Specifications

Number of logic cells: 570

Number of macrocells: 440

Operating frequency: Up to 1879.7 MHz

Number of pins: 144

Package type: TQFP-144

Operating voltage: 3.3V

Operating temperature range: -40°C to +100°C

Maximum latency: 5.4ns
