The 5M80ZT100I5N is a complex programmable logic device (CPLD), part of the MAX® V family. Available in a 100-TQFP package (14 x 14 mm), the device provides a high-performance, low-power logic control solution for industrial, communications, and embedded control systems.

5M80ZT100I5N Key Features

Logic Resources

64 macrocells (Macrocells)

80 Logic Elements/Blocks

79 I/O interfaces supporting multiple input/output configurations

5M80ZT100I5N Performance Parameters

Maximum propagation delay: 7.5ns (typical) to ensure high-speed signal processing.

Maximum clock frequency: 118.3MHz for timing-sensitive applications.

In-system programmable (ISP), supports JTAG debugging for easy field upgrades.

Power supply voltage: 1.71V ~ 1.89V (internal core voltage), adapting to the needs of low-power design.

Operating temperature range: -40°C ~ +100°C (industrial grade), suitable for harsh environments.

Package: 100-TQFP (14×14mm, 0.5mm pin pitch), surface mount (SMT).

RoHS compliant, lead-free and environmentally friendly design.

5M80ZT100I5N Typical Applications

Industrial automation (PLC, motor control)

Communication equipment (protocol conversion, data routing)

Consumer electronics (smart home, display control)

Automotive electronics (body control, sensor interface)
