The AT91SAM9XE256B-CU is a 32-bit ARM926EJ-S microprocessor (MPU) developed by Microchip Technology, featuring a 217-LFBGA package, and is primarily targeted at applications such as industrial control, embedded network devices, and human-machine interfaces (HMI). The chip integrates 256KB of Flash memory, an SDRAM/SRAM controller, and a rich set of peripheral interfaces, making it suitable for high-performance embedded system designs.

AT91SAM9XE256B-CU Core Features

Processor Architecture

ARM926EJ-S 32-bit RISC core, operating at 180MHz, with Java acceleration support (Jazelle technology).

16KB instruction cache (I-Cache) + 16KB data cache (D-Cache) to enhance code execution efficiency.

Storage Resources

256KB on-chip Flash (supports ECC error correction).

56KB SRAM (including 32KB high-speed cache).

SDRAM controller (supports 16/32-bit bus).

Communication Interfaces

10/100Mbps Ethernet MAC (supports MII/RMII).

3× USB 2.0 Host/Device (full-speed/high-speed).

Standard interfaces such as UART, SPI, I²C, and SSC (synchronous serial).

Display and Control

LCD controller (supports TFT screens with a maximum resolution of 1024×768).

Touchscreen interface (4/5-wire resistive).

Power and Reliability

1.8V/2.5V/3.3V multi-voltage domains to accommodate different peripheral device requirements.

Industrial-grade temperature range (-40°C to +85°C), compliant with AEC-Q100 standards (for certain derivative models).

Watchdog (WDT) and undervoltage detection (BOD) enhance system stability.

AT91SAM9XE256B-CU Typical Applications

Industrial HMI panels (PLC control terminals).

Embedded gateways (supporting Ethernet/USB communication).

Medical devices (portable monitors).

Automotive infotainment systems (requires automotive-grade models).
