Service Telephone:86-755-83294757
Trade Name:Voltage Reference
Brand:ADI
Particular Year:23+
Package:SOT-23-3
Delivery Date:New and Original
Stock: 26500pcs
The AD1582ARTZ is a low-cost, low-power, low-dropout, precision bandgap reference voltage source. These are three-pin (series) devices housed in a compact 3-pin SOT-23 surface-mount package. These reference voltage sources feature versatile functionality, making them ideal for use in battery-powered 3 V or 5 V systems where power supply voltage fluctuations are significant and power consumption must be minimised.
The exceptional accuracy and temperature stability of the AD1582ARTZ are achieved through the precise matching and thermal tracking characteristics of its internal components. Utilising a patented design technique for temperature drift curvature correction, the nonlinearity of the voltage output temperature characteristics is minimised.
The AD1582ARTZ series mode devices can provide up to 5 mA of source or sink current to the load and operate effectively with as little as 200 mV of power supply voltage margin. These devices consume a maximum static current of 70 μA, with a power supply voltage variation of only 1.0 μA/V. Compared to traditional shunt devices, these devices offer significant advantages. By using an input series resistor, valuable power supply current is no longer wasted, and high efficiency is achieved across all input voltages.
AD1582ARTZ Features
Series reference voltage source (2.5 V, 3 V, 4.096 V, 5 V)
Low static current: 70 µA (maximum)
Current output capability: ±5 mA
Wide supply voltage range: VIN = VOUT + 200 mV to
12 V
Wideband noise (10 Hz to 10 kHz): 50 µV (RMS)
Rated temperature range:
−40°C to +125°C
Compact SOT-23 surface-mount package
Automotive application certified
AD1582ARTZ Applications
Portable battery-powered devices, such as: laptops, mobile phones, pagers, PDAs, GPS, and DMMs
Computer workstations; suitable for various video RAMDACs
Smart industrial transmitters
PCMCIA cards
Automotive
Disk drives
3 V/5 V, 8-bit/12-bit data converters
Model
Brand
Package
Quantity
Describe
ADI
TSOT-23-6
22300
Precision, wide power supply range, high output drive, low noise reference
ADI
MSOP-8
3000
An 8ppm/°C, 5V reference voltage source certified for automotive applications
ADI
MSOP-8
3000
A reference voltage source of 8ppm/°C and 4.096V certified for automotive applications
ADI
MSOP-8
2500
An 8ppm/°C, 3.0V reference voltage source certified for automotive applications
ADI
MSOP-8
3000
An 8ppm/°C, 2.5V reference voltage source certified for automotive applications
ADI
SOT-23-6
3000
20ppm/°C precision, wide power supply range, high output drive, low noise reference
