CC2745R10E0WRHARQ1 devices is AEC-Q100 complaint wireless microcontrollers (MCUs) supporting Bluetooth Low Energy 5.4 for automotive applications. These devices are optimized for low-power wireless communication in applications such as car access, including passive entry passive start (PEPS), phone as a key (PaaK), and remote keyless entry (RKE).

Feature Of CC2745R10E0WRHARQ1

Support for features in Bluetooth 5.4 and earlier versions:

LE Coded PHYs (Long Range), LE 2Mbit PHY (high speed), advertising extensions, multiple advertisement sets, CSA#2, as well as backward compatibility with earlier Bluetooth Low Energy specifications

Bluetooth Channel Sounding technology support and Algorithm Processing Unit (APU) to enable high accuracy, low cost, and secure phase-based ranging mechanism for distance estimation.

APU enables latency and power-efficient execution of distance-ranging signal processing algorithms, including FFT and super-resolution complex algorithms like MUltiple SIgnal Classification (MUSIC)

ArmCustom Data Extension (CDE) instruction support for machine learning acceleration

Fully qualified Bluetooth software protocol stack included with the SimpleLink™ Low Power F3 Software Development Kit (SDK)

Advanced security features for connected wireless MCUs:

An isolated HSM environment with a dedicated controller handling accelerated cryptographic and random number generation operations

Secure boot and firmware updates with the root of trust enabled by an immutable system ROM

Arm Cortex M33 TrustZone-M based trusted execution environment support

Secure key storage support with HSM and TrustZone-M

Hardware fault sensors to mitigate low-cost, low-effort, non-invasive physical attack threats like voltage glitch injection

Dedicated AES-128 HW accelerator for handling timing-critical link-layer encryption/decryption operations

Ultra-low standby current with full 162KB SRAM retention and RTC operation that enables significant battery life extension, especially for applications with longer sleep intervals

Extended temperature support with the lowest standby current

Integrated BALUN and integrated RF switch to support both transmit and receive operations on the same RF pin, even in the P version; thereby, enabling a reduced bill-of-material (BOM) board layout

Excellent radio sensitivity and robustness (selectivity and blocking) performance for Bluetooth Low Energy

Applications Of CC2745R10E0WRHARQ1

Automotive

– Car access and security systems

• Digital key

• Phone as a key (PaaK)

• Passive entry passive start (PEPS)

• Remote keyless entry (RKE)
