The MCXW716CMFTAR is a secure wireless microcontroller featuring a 96MHz Arm® Cortex®-M33 core and a multi-protocol wireless subsystem that supports Matter, Thread, Zigbee, and BLE. Independent wireless subsystems feature dedicated cores and memory, which can reduce the load on the main CPU, reserve it for primary applications, and allow firmware updates to support future wireless standards.

Furthermore, the MCXW716CMFTAR also provides advanced security through the integrated EdgeLock® Secure Enclave Core Profile and will be supported by NXP's EdgeLock 2GO cloud service for credential sharing.

Peripheral features of MCXW716CMFTAR

"Simulation

16-bit single-ended SAR analog-to-digital converter (ADC), up to 2Msps

Two high-speed analog comparators (CMP) with an 8-bit digital-to-analog converter (DAC)

Reference voltage (Vref) from 1.0V to 2.1V

Timer

Two 6-channel 32-bit timers (TPM) with PWM function, supporting DMA

Two 32-bit low-power timers (LPTMR) or pulse counters with comparison functions

4-channel 32-bit low-power periodic interrupt timer (LPIT), supporting DMA

A 56-bit timestamp timer

A 32-bit second real-time counter (RTC) with 32-bit alarm and independent power supply

The Signal Frequency Analyzer (SFA) provides devices for measuring clock cycles/frequencies and trigger intervals

Communication interface

Two low-power UART (LPUART) modules

Two low-power SPI modules and one MIPI-I3C module

Two low-power I²C (LPI2C) modules that support System Management Bus (SMBus) specification version 2

Optional FlexCAN with CAN and CAN FD, fully implementing CAN specification version 2.0, Part B, FD support

A programmable FlexIO module that supports simulation of UART, I²C, SPI, camera IF, LCD RGB, PWM/ waveform generation

29 GPIOs (48QFN

System peripherals

A DC-DC converter that supports both step-down and bypass operation modes

Stepwise DMA controller with per-channel access rights (secure/non-secure)

A wake-up unit for power-off mode

Application scenarios

The MCXW716CMFTAR wireless MCU is suitable for scenarios that require wireless communication and security, such as smart home devices (like smart door locks and lighting control), industrial Internet of Things nodes, and wearable devices. ‌
