AB5301B is a high-performance Bluetooth 5.4 audio SoC chip launched by Bluetrum, featuring an LQFP48 package, specifically optimised for in-vehicle audio systems and smart voice interaction devices. The chip is based on a RISC-V 32-bit core architecture with a maximum clock speed of 125MHz, supports Bluetooth 5.4 dual-mode (BR/EDR + BLE), and integrates a DSP audio processor, echo cancellation (AEC) algorithm, and dual-channel ADC/DAC, making it suitable for applications such as in-vehicle karaoke, music playback, and voice assistants.

Core Features (AB5301B)

Bluetooth 5.4 dual-mode (BR/EDR + BLE)

Supports A2DP/AVRCP/HFP protocols and is compatible with SBC/AAC audio decoding

Transmission distance >20 metres with strong anti-interference capability

Car audio optimisation

Built-in echo cancellation (AEC) algorithm to reduce in-car feedback

Supports real-time reverb and equalisation adjustment to enhance karaoke experience

Dual microphone input (silicon microphone/electret microphone optional), supports 48 kHz sampling rate

High-quality audio processing

16-bit stereo DAC (signal-to-noise ratio ≥95 dB)

Dual-channel 16-bit ADC (signal-to-noise ratio ≥90 dB)

Supports EQ adjustment and dynamic range compression (DRC)

Rich peripheral interfaces

Supports USB/SD/AUX/HDMI/optical fibre multiple audio inputs

Provides I2S/PCM/UART/GPIO expansion interfaces

Low-power design

Standby current <10μA, playback mode power consumption <15mA

Supports 12V car power supply/USB 5V power supply

Technical specifications (AB5301B)

Bluetooth version: 5.4 dual-mode (BR/EDR + BLE)

Package: LQFP48

Clock speed: 125    MHz

Storage: 8Mbit Flash

ADC/DAC: 16-bit stereo

Signal-to-noise ratio (DAC):    ≥95    dB

Operating voltage: 3.3V to 12V

Operating Temperature: -40°C to +85°C

Typical Applications (AB5301B)

In-car karaoke system (supports reverb and voice modification)

Smart voice assistant (voice control + music playback)

In-car Bluetooth speaker (high-fidelity sound quality)

Dashcam audio module
