The LT6657BHMS8-3 is a low-dropout reference that can be powered by a power supply that is only 50mV higher than the output voltage (up to 40V). The LT6657BHMS8-3 achieves a drift of 3ppm/°C, a predictable temperature operation mode, and an initial voltage accuracy of 0.1%.

Technical parameters

Model: LT6657BHMS8-3

Reference type: Series

Output type: Fixed

Voltage - Output (minimum/Fixed) : 3V

Current - Output: 10 mA

Tolerance: ±0.1%

Temperature coefficient: 3ppm/°C

Noise - 0.1Hz to 10Hz: 0.5ppmp-p

Noise - 10Hz to 10Hz: 0.8 PPM ms

Voltage - Input: 3.5V to 40V

Current - Power supply: 1.2mA

Operating temperature: -40°C to 125°C (TJ)

Installation type: Surface mount type

Packaging/Shell: 8-MSOP

Application field

The LT6657BHMS8-3 is suitable for various application scenarios that require high-precision, low-noise and low-drift voltage references, including but not limited to:

High-temperature industry

High-resolution data acquisition system

Instruments and process control

Automobile control and monitoring

Medical equipment

Parallel reference and negative voltage reference
