The R7FA4L1BD4CFP is a low power MCU based on 80MHz Arm Cortex-M33 and supports TrustZone, segment code LCD controller and advanced security features. The operating voltage of R7FA4L1BD4CFP is as low as 1.6V, and the standby current is as low as 1.65µA. It also features multiple low-power consumption functions, allowing users to dynamically optimize power consumption/performance according to application requirements.

Performance characteristics and application fields

The R7FA4L1BD4CFP microcontroller has the following main features:

80MHz Arm Cortex-M33 supporting TrustZone

512KB dual-block flash memory supporting BGO

64KB SRAM supporting 32KB parity check and 32KB ECC

8KB data flash memory

Operating current: 168µA/MHz, standby current: 1.65µA

Rapid wake-up within 3.5µS (from MOCO)

Six SCI multi-functional serial ports (UART, simple SPI, simple I2C)

Two low-power UART interfaces supporting 32kHz

Independent SPI/I2C multi-master interface

I3C interface

USB 2.0 FS

CAN FD

Four-wire SPI supporting XIP

32-bit and 16-bit timers, 32-bit ultra-low power timer

2 x Watchdog timer

Real-time Clock (RTC

12-bit ADC and 12-bit DAC

Low-power analog comparator

Temperature sensor

8 x 48-segment LCD driver

12-channel capacitive touch

Serial Audio Interface (SSI)

Advanced security engine support: TRNG, Unique ID, AES, ECC, SHA

Application field

The R7FA4L1BD4CFP microcontroller is widely used in the following fields:

Electrical appliances, small electrical appliances, household appliances.

Smart home and building automation: access control systems, internal communication systems, thermostats, security panels, alarm sensors, smart locks, voice recognition.

Office automation: asset management, printers, QR code readers, fingerprint scanners.

Healthcare: Heart rate monitors, blood glucose meters, blood oxygen meters, blood pressure monitors.

Artificial intelligence speech recognition application
