The R5F3650TDFB is a 16-bit high performance microcontroller belonging to the M16C/65 series. This series of microcontrollers is widely used in various industrial, automotive and consumer electronics products due to its excellent performance, rich peripheral functions and low power consumption.

R5F3650TDFB Technical Data

CPU core: M16C/60, 16-bit architecture, maximum operating frequency 32MHz

Memory capacity: 768KB Flash, 47KB RAM

Operating Voltage: 2.7V to 5.5V

Operating temperature range: -40°C to +85°C

Package: 100-pin LFQFP (14x14mm)

ADC: 10-bit, 26-channel

DAC: 8-bit, 2-channel

Timer: 16-bit, 11-channel

Peripheral interface: Supports various communication interfaces such as UART, I²C, SPI, etc.

R5F3650TDFB Product Features

High-performance processing capability: The M16C/60 core, combined with a 32MHz operating frequency, provides powerful computing power and real-time performance, enabling it to respond quickly to a variety of complex control tasks.

Large storage capacity: 768KB flash memory can store a large amount of program code, and 47KB RAM provides sufficient memory support for data processing, making it suitable for complex embedded applications.

Rich peripheral functions: 26-channel 10-bit ADC and 2-channel 8-bit DAC can accurately acquire analogue signals and output analogue signals to meet a variety of sensor interfaces and control requirements, and the 11-channel 16-bit timer can achieve accurate timing control and pulse signal generation.

Flexible communication interfaces: Supporting various standard communication protocols such as UART, I²C and SPI, it is convenient to exchange data with external devices, such as sensors, displays, other microcontrollers and so on.

Low-power design: Ensures high performance with low power consumption, suitable for power-sensitive applications such as battery-powered portable devices.

Wide Operating Voltage and Temperature Range: A wide operating voltage range of 2.7V to 5.5V ensures compatibility and stability in different power supply environments. The -40°C to +85°C operating temperature range enables normal operation in a variety of harsh environments and meets the requirements of industrial and automotive applications.
