R5F52608AGFM is a member of the RX260 microcontroller (MCU) product group launched by Renesas, featuring an outstanding energy efficiency ratio and advanced touch functionality. Based on the RXv3 core, it can achieve a performance of 355 CoreMark at a main frequency of 64MHz and is suitable for applications in consumer electronics, industrial automation, and other fields.

The main features of R5F52608AGFM include:

64MHz RXv3 core (355CoreMark)

Low power consumption (operating: 69μA/MHz, standby: 1μA)

Maximum 512KB code flash memory and 128KB SRAM

8KB data flash memory, which can provide data storage functions similar to EEPROM

Operating voltage range: 1.6V to 5.5V

Operating temperature range: -40°C to 85°C or -40°C to 105°C

High-speed on-chip oscillator, accuracy +/- 1.0%

Capacitive touch sensing unit (CTSU2SL

Safety protection (flash memory protection

UART, SPI, I2C

16-bit / 32-bit universal PWM timer, 16-bit low-power timer, 16-bit comparation-matching timer, 8-bit timer, RTC

12-bit A/D converter, 8-bit D/A converter, comparator, temperature sensor

64-LFQFP pin package

Application field

The target applications of R5F52608AGFM cover household appliances, building automation, battery-powered equipment (such as smart locks and electric bicycles), and industrial control fields.
