The SPC563M64L5COAR is a high performance 32-bit automotive microcontroller based on Power Architecture® technology and designed for automotive powertrain applications.

SPC563M64L5COAR Product Features

High-performance core: 32-bit Power Architecture® Book E-compliant e200z335 CPU core with Variable Length Encoding (VLE) enhancements to reduce code size.

Mass storage: Up to 1.5 MB of on-chip Flash with Flash controller and Fetch Accelerator for single-cycle access at 80 MHz; up to 94 KB of on-chip static RAM, including up to 32 KB of standby RAM.

Extensive peripheral interfaces including 32-channel Direct Memory Access (DMA), Interrupt Controller (IN IC) with 364 selectable priority interrupt sources, Frequency Modulated Phase Locked Loop (FMPLL), Calibrated External Bus Interface (EBI), System Integration Unit (SIU), 32-channel Enhanced Time Processing Unit (eTPU), 16-channel Enhanced Modular Input/Output System (eMIOS). Input/Output System (eMIOS), Enhanced Queue Analogue to Digital Converter (eQADC), etc.

Communication interfaces: Equipped with two microsecond bus-compatible Deserialised Serial Peripheral Interface (DSPI) modules, two LIN-compatible Enhanced Serial Communication Interface (eSCI) modules, and two CAN 2.0B-enabled Controller Area Network (FlexCAN) modules.

Development support: IEEE 1149.1 (JTAG) test access port and Nexus interface for easy debugging and development.

Power Management: On-chip voltage regulator controller provides 1.2V and 3.3V internal power from a 5V external supply.

Operating temperature range: -40°C to +125°C.

Package: LQFP-144 (20x20x1.4 mm) package.

SPC563M64L5COAR Product Attributes

Product Category: 32-bit Microcontrollers - MCUs

Series: SPC563M64L5

Mounting Style: SMD/SMT

Package / Case: LQFP-144

Core: e200z335

Programme memory size: 1.5 MB

Data RAM size: 94 kB

Data bus width: 32 bit

ADC resolution: 2 x 8 bit/10 bit/12 bit

Maximum clock frequency: 80 MHz

Number of inputs/outputs: 105 I/Os

Supply voltage - min: 5 V

Supply voltage - max: 5 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 125 C
