Commodity Model:R5F100SHAFB

Trade Name:16-bit Microcontroller - MCU

Brand:Renesas

Particular Year:23+

Package:LFQFP-128

Delivery Date:New and Original

Stock: 5000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Renesas
Model
R5F100SHAFB
Package
LFQFP-128
Describe
16-bit Microcontrollers - MCU 16BIT MCU RL78/G13 192K/16K QFP128

Product Description

The R5F100SHAFB is a 16-bit RL78 series microcontroller featuring high performance and low power consumption.The R5F100SHAFB features an RL78 core operating at up to 32MHz with 192KB of Flash, 16KB of SRAM, and 8KB of data flash. It supports multiple communication interfaces, including 4 UART, 8 SPI, and 10 I²C channels, and features a 26-channel 10-bit ADC and a 1-channel 12-bit DAC. The chip operates over the voltage range of 1.6V to 5.5V, over the temperature range of -40°C to +85°C, and is available in a 128-pin LQFP package.


R5F100SHAFB Product Attributes

Product Category: 16-Bit Microcontrollers - MCUs

Core: RL78

Program memory size: 192 kB

Data RAM size: 16 kB

Package / Case: LFQFP-128

Maximum clock frequency: 32 MHz

ADC resolution: 8 bit/10 bit

Number of inputs/outputs: 120 I/Os

Supply voltage - min: 1.6 V

Supply voltage - max: 5.5 V

Mounting style: SMD/SMT

Data bus width: 16 bit

Minimum operating temperature: - 40 C

Maximum operating temperature: + 85 C

Series: RL78/G13

Analogue supply voltage: 1.6 V to 5.5 V

Data Ram Type: SRAM

Interface Type: I2C, UART

Number of ADC channels: 26 Channel

Number of timers/counters: 16 x 16 bit

Processor family: RL78/G13


Applications: R5F100SHAFB

The R5F100SHAFB is suitable for a variety of application scenarios, including but not limited to:

Industrial Control: For precise control systems and automation equipment.

Smart Home: Used in smart home systems to provide a convenient and comfortable living environment.

Home Appliance Control: Supports safety standards for home appliances and is applicable to a wide range of home appliances.

Consumer Electronics: For consumer electronics products that require low power consumption and high performance.
