The ATMEGA1608-MFR is a microcontroller featuring an 8-bit AVR® processor with hardware multiplier, running at up to 20 MHz, with up to 16 KB of Flash, 2 KB of SRAM and 256 bytes of EEPROM in a 32-pin package. The family features the latest core-independent peripherals with low power consumption, including the event system, intelligent analogue and advanced peripherals.

Features Of ATMEGA1608-MFR

Hardware multiplier

Three sleep modes

Idle

Standby

Power-down

Event system

Watchdog Timer (WDT)

Power On Reset (POR)

Undervoltage Detection (BOD)

Single Pin Programming and Debug Interface (UPDI)

16-Channel 10-Bit ADC with Voltage Reference

Analogue Comparator (AC)

Configurable Custom Logic (CCL)

5x 16-bit Timers (TCA / TCB)

Cyclic Redundancy Check (CRC / SCAN)

SPI / I2C / USART

ATMEGA1608-MFR Specifications

Product Category: 8-bit Microcontrollers -MCUs

Core: AVR

Programme memory size: 16 kB

Data RAM size: 2 kB

Package / Case: VQFN-32

Maximum clock frequency: 20 MHz

ADC resolution: 10 bit

Number of inputs/outputs: 27 I/Os

Supply voltage - min: 1.8 V

Supply voltage - max: 5.5 V

Mounting style: SMD/SMT

Data bus width: 8 bit

Minimum operating temperature: - 40 C

Maximum operating temperature: + 125 C

Family: ATmega1608

Data Ram Type: SRAM

Data ROM Size: 256 B

Data Rom Type: EEPROM

Interface Type: I2C, SPI, UART

Humidity Sensitivity: Yes

Number of ADC Channels: 12 Channel

Number of Timers/Counters: 4 Timer
