The STM8S207R8T6 is a high-performance 8-bit microcontroller (MCU) belonging to the mainstream product line of the STM8S series. The chip is based on the STM8 core, featuring a 3-stage pipeline and Harvard architecture, delivering up to 20 MIPS performance at a 24MHz clock frequency. It is suitable for various application scenarios such as industrial control, consumer electronics, and automotive electronics, offering low power consumption, high integration, and rich peripheral resources.

STM8S207R8T6 Product Features

High-performance core: Utilises the STM8 8-bit core with a maximum clock frequency of 24MHz, delivering 20 MIPS processing capability

Memory capacity:

Program memory: 64KB Flash

Data memory: 4KB SRAM

EEPROM: 2KB

Rich peripheral interfaces:

Communication interfaces: Supports I²C, SPI, USART, and CAN

Analogue Functions: 10-bit ADC with up to 16 channels.

Timers: 2 16-bit general-purpose timers, 1 8-bit basic timer

Operating Voltage: 2.95V to 5.5V

Operating Temperature Range: -40°C to +85°C

Package type: 64-pin LQFP (10x10mm)

Low-power design: Features multiple low-power modes, such as standby, active stop, and stop

Other features:

Independent watchdog (with independent clock source)

Clock security system with clock monitor

Up to 52 external interrupts

STM8S207R8T6 Application Areas

Industrial control: Suitable for PLC control, sensor interfaces, motor control, etc.

Smart home: Such as smart sockets, temperature controllers, etc.

Consumer electronics: Such as smart watches, smart home appliances, game consoles, etc.

Automotive electronics: Can be used for sensor monitoring, lighting control, and in-vehicle information systems within vehicles.
