The K32L2B21VFT0A microcontrollers (MCUs) feature a low-power Arm® Cortex®-M0+ core and a range of power-optimised integrated peripherals.The K32 L2 MCUs are available with Flash options from 64KB to 512KB and SRAM options from 32kB to 128kB. The devices also feature high-precision mixed-signal integration, including a high-resolution 16-bit ADC with single-pair and differential-pair input mode options and a DMA-enabled 12-bit DAC, which relieves the core of its burden and allows it to perform other important tasks.

The K32L2B21VFT0A also comes with a range of low-power serial peripherals (supporting asynchronous operation in low-power modes), SPI interfaces, I2C, USB full-speed 2.0 (with support for transistor-less operation), the NXP FlexIO module (with support for emulation of additional UARTs, SPIs, I2Cs, and PWMs), and other serial modules. The device also integrates other features such as segmented LCD interfaces supporting up to 24x8 or 28x4 segments for different applications in the consumer, IoT and industrial sectors.

Product Attributes

Core Processor: ARM® Cortex®-M0+

Core specification: 32-bit single core

Speed: 48MHz

Connectivity: FlexIO, I²C, SPI, TSI, UART/USART, USB

Peripherals: DMA, LCD, PWM, WDT

Program memory capacity: 128KB (128K x 8)

Program memory type: Flash

EEPROM capacity: -

RAM Size: 32K x 8

Voltage - Supply (Vcc/Vdd): 1.2V

Data Converter: -

Oscillator Type: Internal

Operating Temperature: -

Mounting Type: Surface Mount

Package/Shell: 48-UFQFN Exposed Pad

Supplier Device Package: 48-QFN (7x7)

Applications

• Industrial

• Building HVAC

• Door Locks

• Factory Automation

• Lighting Control

• Robotics

• Security and Access Control

• Smart Thermostats

• Mobile Devices

• Low Power Applications

• USB Peripherals
