The MKV30F64VFM10 is a 32-bit microcontroller (MCU) from NXP's Kinetis KV3x series, based on the Arm® Cortex®-M4 core, with a clock speed of 100MHz, integrated DSP instruction set and floating-point unit (FPU), specifically designed for applications such as motor control, industrial automation, and automotive electronics.

Basic Information

Product Model: MKV30F64VFM10

Core Architecture: 32-bit Cortex-M4, supporting DSP and floating-point operations, suitable for complex algorithms (e.g., FOC motor control).

Memory Configuration: 64KB Flash + 16KB SRAM, meeting real-time control requirements.

Package: 32-HVQFN (5×5mm), suitable for compact designs.

Application Areas: BLDC/PMSM motor drives, industrial servo control, smart home appliances, etc.

MKV30F64VFM10 Key Features

100MHz Cortex-M4 + FPU, supporting DSP instructions, optimising FOC algorithm computation efficiency.

Dual 16-bit ADCs (1.2MSPS) for synchronous sampling of current/voltage, enhancing control accuracy.

FlexTimer (FTM): Supports 6 PWM outputs with integrated quadrature decoder (QDEC).

Programmable Delay Block (PDB): Precisely controls PWM timing to reduce CPU intervention.

Operating temperature: -40°C to +105°C, compliant with industrial and automotive electronics standards.

Dual watchdog (WDT), meeting IEC 60730 functional safety requirements.

Communication interfaces: I²C (1 Mbps), SPI, UART1.

Analogue peripherals: 2×16-bit ADCs, 1×12-bit DAC, analogue comparator (ACMP).

MKV30F64VFM10 Key Parameters

Core: Arm Cortex-M4 (with FPU)

Clock speed: 100MHz

Flash/RAM: 64KB / 16KB

ADC: 2×16-bit (1.2MSPS)

DAC: 1×12-bit

PWM Channels: 6 channels (FTM)

Communication Interfaces: I²C, SPI, UART

Operating Voltage: 1.71V to 3.6V

Package: 32-HVQFN (5×5mm)

Temperature Range: -40°C to +105°C
