The ATA5724P3C-TKQW is a multichip PLL receiver device in a TSSOP20 package. It has been developed specifically to meet the needs of RF low-cost data transmission systems with data rates from 1kbit/s to 10kBbit/s in Manchester or biphase code. Its main applications are in keyless entry systems, tyre pressure monitoring systems, telemetry and security technology systems.

Specifications - ATA5724P3C-TKQW

Frequency: 433MHz

Sensitivity: -113dBm

Modulation or Protocol: UHF

Application: General Purpose

Current - Receive: 11mA

Antenna Connector: PCB, Surface Mount

Voltage - Supply: 4.5V ~ 5.5V

Operating Temperature: -40°C ~ 105°C

Mounting Type: Surface Mount

Package/Shell: 20-TSSOP (0.173’, 4.40mm Width)

Supplier Device Package: 20-SSO

Benefits

High level of integration and low BOM list

Uses low-cost 13MHz crystal

Lowest average application current consumption due to self-polling feature

Reuse of Atmel® ATA5743 software

Global coverage on a single PCB due to pin compatibility of 3 versions

Application Scenarios

Wireless communication

For efficient data transfer in scenarios such as remote controls, wireless sensor networks, etc.

Industrial Control

Wireless control module for industrial automation equipment to increase system flexibility.

RFID System

RF receiver modules for RFID readers, supporting long-distance signal reception.

Consumer Electronics

Applied to smart home equipment, such as wireless doorbell, intelligent lighting control.
