The WNSC2D401200CW is a dual channel silicon carbide Schottky diode in a TO247 plastic package designed for high frequency switch mode power supplies.

Features and Benefits

Highly stable switching performance

High forward surge capability IFSM

Very fast reverse recovery time

Efficiency better than silicon diode alternatives

Reduced losses in associated MOSFETs

Reduced EMI

Reduced cooling requirements

RoHS compliant

High junction operating temperature capability (Tj (max) = 175 °C)

AEC-Q101 certified

WNSC2D401200CW Technical Specifications

 Diode configuration: 1 pair of common cathodes

Technology SiC (Silicon Carbide): Schottky

Voltage - DC reverse (Vr) (max): 1200 V

Current - Average Rectification (Io) (per diode): 40A

Voltage - Forward (Vf) at Different If: 1.8 V @ 20 A

Speed: No Recovery Time > 500mA (Io)

Reverse Recovery Time (trr): 0 ns

Current at different Vr - reverse leakage: 200 µA @ 2000 V

Operating temperature: - Junction 175°C

Mounting Type: Through Hole

Package/Housing: TO-247-3

Supplier Device Package: TO-247-3

Applications

Electric Vehicle Onboard Chargers

Electric Vehicle DC-DC Converters

Other Electric Vehicle High Voltage Systems
