Service Telephone:86-755-83294757
Trade Name:SHARC Processor
Brand:ADI
Particular Year:25+
Package:LQFP-100
Delivery Date:New and original
Stock: 3000pcs
The ADSP-21488KSWZ-3A is part of ADI's fourth-generation SHARC® processor offering high performance (350 MHz) in an LQFP package. This level of performance makes the ADSP-21488KSWZ-3A particularly suitable for meeting the needs of the automotive audio and industrial control sectors.
In addition to powerful kernel performance, the AADSP-21488KSWZ-3A includes additional processing modules such as FIR, IIR, and FFT accelerators to further improve the overall performance of the system. This device has a new feature called Variable Instruction Set Architecture (VISA) that enables code reduction of 20 to 30 percent and increases memory size availability. Fourth-generation DSPS can connect to external memory by providing a seamless interface for 16-bit wide SDR SDRAM.
Features
The ADSP-21488KSWZ-3A processor has the following features:
350 MHz core clock speed
3 Mbits on-chip RAM
FIR, IIR and FFT accelerators
16-bit wide SDR SDRAM external memory interface
Digital Application Interface (DAI) supports user-defined access to peripherals, including S/P DIF transmitters/receivers and 8-channel asynchronous sampling rate converters
Fully enhanced DMA engine, including distributed/aggregated DMA, delay line DMA
Eight serial ports (SPORT) with support for I2S, left-justified sample pairs, DSP serial and TDM modes
Two SPI compatible ports, supporting master-slave mode
UART and dual-wire port
16 pulse width modulation (PWM) channels
3 fully functional timers
100-pin LQFP EPAD package
Commercial and industrial grade temperature ranges
Model
Brand
Package
Quantity
Describe
ADI
LQFP-100
3000
High-performance fourth generation SHARC digital signal processor
ADI
LQFP-176
3000
High-performance fourth generation SHARC digital signal processor
A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.
A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.
A: at present, our self-employed brands TI,ST,ADI,NXP,LATTICE,CYPRESS,INFINEON,XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.
A: You can inquire through the website, or by phone and email.
A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.
A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
