The LTC2378IDE-20 is a low-noise, low-power, high-speed 20-bit successive approximation register (SAR) ADC. The device uses a single 2.5V operating power supply with a fully differential input range of ±VREF (VREF varies from 2.5V to 5.1V). The LTC2378-20 consumes only 21mW of power and achieves ±2ppm INL (maximum), no leakage code (at 20 bits), and 104dB SNR.

The LTC2378-20 features a high-speed SPI-compatible serial interface that supports 1.8V, 2.5V, 3.3V and 5V logic, as well as a Daisy chain mode. The high throughput rate and cycle-free delay of 1Msps make the LTC2378-20 ideal for a wide range of high-speed applications. An internal oscillator is responsible for setting the conversion time, alleviating external timing considerations. The LTC2378-20 is automatically powered off between conversion operations, thereby reducing power consumption with the sampling rate.

Technical specification

Resolution: 20 bit

Number of channels: 1 Channel

Sampling ratio: 1 MS/s

Input type: Differential

Structure: SAR

Analog supply voltage: 2.5V

Package/housing: DFN-16

Development kit: DC1925A-A, DC2135A

DNL - differential nonlinearity: 0.2 LSB

Gain error: 10.5 LSB

INL - Integral nonlinearity: 0.5 LSB

Pd-power dissipation: 21 mW

Product type: ADCs - Analog to Digital Converters

Reference type: External

SFDR - Spury-free dynamic range: 128 dB

Shutdown: Shutdown

SINAD - Signal noise and distortion rate: 104 dB

THD - Total harmonic distortion: -125 dB
