The AD2S1210WDSTZ is a 10-bit to 16-bit resolution rotary digitizer with integrated on-chip programmable sine wave oscillator that provides sine wave excitation for the rotary converter. The AD2S1210WDSTZ has been approved by an independent certification body for use in automotive safety Integrity Level B applications that meet ISO 26262 standards.

Applications

Dc and AC servo motor control

Encoder simulation

Electric power steering

Electric vehicle

Integrated starter/alternator

Motor vehicle motion detection and control

Product features

1. Ratio tracking conversion. The Type II tracking loop enables continuous output of position data with no conversion delay. It also suppresses noise and provides tolerance for harmonic distortion of reference and input signals.

2. System fault detection. The fault detection circuit can detect rotational signal loss, out-of-range input signals, input signal mismatch, or position tracking loss. Each fault detection threshold can be individually programmed by the user to optimize for a specific application.

4, programmable excitation frequency. The excitation frequency can be easily set to multiple standard frequencies in the range of 2 kHz to 20 kHz.

5, 3 formats of location data. Absolute angular position data from 10 to 16 bits can be accessed through a 16-bit parallel port or a 4-line serial interface. Incremental encoder simulation is in standard A-quad-B format and provides directional output.

6, digital speed output. A 10-bit to 16-bit signed digit speed can be accessed through a 16-bit parallel port or a 4-line serial interface.
