The AD9683BCPZ-170 is a 14-bit ADC with a maximum sample rate of 170 MSPS designed to provide a solution for low-cost, small size, wide bandwidth, and versatile communications applications.

The AD9683 kernel adopts multi-level, differential pipelining architecture, and integrates output error correction logic. The ADC core has a wide band input and supports various input ranges that users can choose from. Integrated reference voltage source simplifies design. Duty cycle stabilizers can be used to compensate for fluctuations in the ADC clock duty cycle, allowing the converter to maintain excellent performance. The JESD204B high-speed serial interface reduces board wiring requirements and reduces the number of pins required for receiving devices.

The ADC output data is sent directly to the JESD204B serial output channel. These outputs are set to CML levels. Data can be sent over the channel at a maximum sampling rate of 250 MSPS, resulting in a channel rate of 5 Gbps. The device provides synchronous inputs (SYNCINB± and SYSREF±).

Product features

1, Integrated 14-bit, 170 MSPS/250 MSPS ADC.

2, configurable JESD204B output module supports up to 5 Gbps channel rate.

3, the on-chip phase-locked loop (PLL) allows the user to provide a single ADC sampling clock, the corresponding JESD204B data rate clock is generated by the PLL multiplied by the ADC sampling clock.

4, support optional RF clock input to simplify the system board design.

5, patented differential inputs maintain excellent signal-to-noise ratio (SNR) performance at input frequencies up to 400 MHz.

6, 1.8V single power supply.

7, the standard serial port interface (SPI) supports a variety of product features and functions, such as: control clock DCS, power down mode, test mode, reference voltage mode, over range rapid detection and serial output configuration.
