The MP23ABS1TR is a compact, low-power microphone built with a capacitive sensing element and an IC interface.

The sensing element, capable of detecting acoustic waves, is manufactured using a specialized silicon micromachining process to produce audio sensors.

The MP23ABS1TR has an acoustic overload point of 130 dBSPL with a typical 64 dB signal-to-noise ratio.

The sensitivity of the MP23ABS1 is -38 dBV ±1 dB @ 94 dBSPL, 1 kHz.

The MP23ABS1TR is available in a package compliant with reflow soldering and is guaranteed to operate over an extended temperature range from -40 °C to +85 °C.

Features

Single supply voltage operation 1.52 V - 3.6 V

Omnidirectional sensitivity

High signal-to-noise ratio

High acoustic overload point: 130 dBSPL typ.

Package compliant with reflow soldering

Enhanced RF immunity

Ultra-flat frequency response

Low latency

Ultra-low-power: 150 μA max

ECOPACK, RoHS, and “Green” compliant

Applications

Mobile phones

Wearables

Hearables

Smart speakers

Active noise-canceling headsets
