Trade Name:ADA4570BRZ
Data Manual:ADA4570BRZ.pdf
Brand:ADI
Particular Year:23+
Package:8-SOIC
Delivery Date:New original
Stock: 3000pcs
The ADA4570BRZ is an integrated AMR Angle sensor and signal regulator with a differential output. The ADA4570 consists of two bare chips in a package, an AMR sensor, and a fixed-gain instrumentation amplifier. When the magnetic field rotates in the x- and Y-axis (X-Y) planes, the ADA4570 provides angle-dependent amplified differential cosine and sine output signals. The output voltage range is proportional to the supply voltage.
Product Specifications:
For measurement: Angle
Technology: Magnetoresistance
Rotation Angle - Electrical, mechanical: 180° (±90°), continuous
Linear range: -
Output: Analog voltage
Output signal: Cosine, Sine
Actuator type: External magnet, not included
Linearity: -
Resistance tolerance: -
Voltage - Power supply: 2.7V ~ 5.5V
Mounting type: Surface mount type
Terminal type: SMD (SMT) connector
Operating temperature: -40°C ~ 125°C
Package/housing: 8-SOIC (0.154", 3.90mm wide)
Supplier device package: 8-SOIC
Model
Brand
Package
Quantity
Describe
BROADCOM
QFN 24
3000
Rotary encoder magnetic programmable commutation, PWM, SPI, vertical with index (incremental) orthogonal output
Allegro
TSSOP-14
3000
Precision Angle Sensor IC with On-Chip Linearization, SENT, SPI, and PWM Output
INFINEON
DSO-8
3000
Magnetoresistive sensor Angle external magnet, without SMD (SMT) connector PG-DSO-8
INFINEON
DSO-8
3000
Magnetoresistive sensor Angle external magnet, excluding Gull Wing PG-DSO-8
INFINEON
DSO-8
3000
Magnetoresistive sensor Angle external magnet, excluding Gull Wing PG-DSO-8
INFINEON
DSO-8
3000
Magnetic resistance sensor Angle external magnet, excluding Gull Wing PG-DSO-8-16
INFINEON
16-TSSOP
3000
Magnetoresistive sensor Angular, linear, rotating outer magnet, gull wing free
INFINEON
16-TSSOP
3000
Magnetoresistive sensor Angular, linear, rotating outer magnet, gull wing free
Allegro
14-TSSOP
3000
Hall effect sensor linear, rotating position external magnet, gull wing free
ADI
8-SOIC
3000
Magnetoresistive sensor angular external magnet, without SMD (SMT) connectors
