The AS5145A-HSSM is a non-contact rotating position magnetic position sensor that can achieve precise Angle measurement within a 360° range within an extended ambient temperature range of -40 ° C to +150 ° C. The AS5145A-HSSM can output real-time absolute Angle information through the SSI serial interface and PWM signal, with a resolution of 0.0879°= 4096 positions per revolution. The incremental ABI output interface can be pre-programmed as 10 bits =1024 positions.

Features of AS5145A-HSSM

High-resolution non-contact 360° full-range rotation position sensing

Simple user-programmable zero position and Settings

Serial communication interface (SSI), 10-bit pulse width modulation (PWM) output, ABI output interface

The rotational speed can reach up to 30,000 rpm

The fault monitoring mode can monitor the position of the magnet and power failure

Serial reading function, suitable for multiple AS5145 devices interconnected by daisy chain

Advantages of AS5145A-HSSM

It features outstanding reliability and durability

Simple programming

Multiple interfaces can be provided

Suitable for motor applications

Supports fault diagnosis function

Easy to set up

Application scenarios

Industry

Robot

Automobiles and Mobility

Position and Angle sensing
