For picture reference, please see the specifications
< >

Commodity Model:A4911KJPTR-T-1

Trade Name:Motor Driver

Brand:Allegro

Particular Year:23+

Package:LQFP-48

Delivery Date:New and Original

Stock: 30000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Allegro
Model
A4911KJPTR-T-1
Package
LQFP-48
Describe
Multi-phase Motor Driver NMOS SPI 48-LQFP-EP (7x7)

Product Description

The A4911KJPTR-T-1 is a dual-channel triple motor control chip with an advanced CMOS process and integrated dual-channel power management system. Using the A4911KJPTR-T-1 you can control the drive motor as well as the LCD display fan with adjustable three-way DC rotation status. Its unique voltage output function improves the brightness and resolution of the LCD display and reduces noise pollution. The A4911KJPTR-T-1 features high speed, low impedance and high current output, and a low power consumption design concept that helps to balance energy efficiency with system cost. It has powerful motor control functions and can directly drive three synchronous motors to drive one fan rotation for high torque output functions. The expandable dual-channel interface supports a wide range of control algorithms including ADC.


Product attributes

Motor type - stepper: multi-phase

Motor type - AC, DC: Brushless DC (BLDC)

Features: Driver - fully integrated, control and power stages

Output configuration: Half Bridge (3)

Interface: SPI

Technology: NMOS

Stepping resolution: -

Applications: Automotive grade

Current - Output: -

Voltage - supply: -

Voltage - Load: -

Operating temperature: -40°C ~ 150°C

Mounting Type: Surface Mount Type

Package / Case: 48-LQFP Exposed Pad

Supplier Device Package: 48-LQFP-EP (7x7)


This chip can be used in a wide range of applications in new energy vehicles, autonomous driving and electric vehicles.


Associated Products

Model

Brand

Package

Quantity

Describe

L9997ND013TR

ST

SO-20

4000

Motor driver CMOS, DMOS parallel 20-SO

NCV7601PG

TI

PDIP-16

3000

Power switch/driver 1:1 Bipolar 1.8A 16-PDIP

NCV7720DQAR2G

ON

SSOP24

5000

Motor Driver Power MOSFET SPI 24-SSOP-EP

L6229D

ST

SO-24

3600

DMOS driver for three-phase brushless DC motors

TLE9166EQ

INFINEON

TSDSO-32

2500

Motor driver NMOS PWM, SPI PG-TSDSO-32

TLE94003EP

INFINEON

TSDSO-14

2500

Half-bridge (3) driver DC motor, universal DMOS 2A TSDSO-14

IMC302A-F064

INFINEON

LQFP-64

3000

PMSM/BLDC motor & PFC controller with additional 32-bit microcontroller

IMC101T-F06

INFINEON

LQFP-64

2000

Motor driver simulation, PWM PG-LQFP-64

IMC101T-F048

INFINEON

LQFP-48

2500

Motor driver CMOS simulation, PWM PG-LQFP-48

L6482HTR

ST

HTSSOP38

2500

Bipolar Motor Driver Power MOSFET SPI 38-HTSSOP
