The ADV7535BCBZ device provides MIPI® Display Serial Interface (MIPI/ DSI) input receiver and High Definition Multimedia Interface (HDMI®) transmitter output. The DSI receiver input only supports DSI video mode, specifically, only the non-burst mode of synchronous pulses. DSI receivers offer up to four MIPI/DSI data channels, each with a maximum transmission rate of 891 Mbps. The HDMI transmitter supports video resolutions with TMDS clock rates up to 148.5 MHz. The ADV7535 also offers an audio input port to plug audio into an HDMI stream.

Applications:

Mobile device

Cellular phone

Digital camera

Digital camera

Personal media player

game

ADV7535BCBZ features:

Low power MIPI/DSI receiver

Low power HDMI/DVI transmitter, ideal for portable applications

The CEC controller and extended message buffer (3 messages) reduce system overhead

Compatible with DVI v.1.0

Embedded HDCP keys support HDCP 1.3

1.8V and 3.3V power supply, ultra-low power consumption

The audio input accepts logic levels from 1.8V to 3.3V

• 1.Is the inventory and price seen on the platform accurate?

  A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.

• 2.Are all our products genuine?

  A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.

• 3.Can you provide the qualification certificate of the original factory or agent?

  A: at present, our self-employed brands TI，ST，ADI，NXP，LATTICE，CYPRESS，INFINEON，XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.

• 4.Can I make an inquiry through the company's website?

  A: You can inquire through the website, or by phone and email.

• 5.When can I deliver the goods after placing an order? How long will it take to get there?

  A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.

• 6.Can the company issue an invoice?

  A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
