Description:

The IKW75N65ES5 is a 650 V hard switch TRENCHSTOP™ 5 S5 IGBT in the TO247 package, which is suitable for applications with switching frequencies between 10 kHz and 40 kHz, enabling high efficiency and faster time-to-market. Reduce circuit design complexity and optimize PCB bill of material costs.

Specifications:

Product: IKW75N65ES5

Technology: Si

Package/housing: TO-247-3

Installation style: Through Hole

Configuration: Single

Maximum collector-emitter voltage VCEO: 650 V

Collector-emitter saturation voltage: 1.42V

Maximum grid/emitter voltage: -20 V, 20 V

Continuous collector current at 25 C: 80 A

Pd-power dissipation: 395 W

Operating temperature: -40 °C to + 175°C

Series: TRENCHSTOP 5 S5

Package: Tube

Trademark: Infineon Technologies

Grid-emitter leakage current: 100 nA

Height: 20.7mm

Length: 15.87mm

Product type: IGBT Transistors

Applications:

• Resonant converter

• Uninterruptible power supply

• Welding converter

• Medium and high-end switching frequency converter
