AMC7891SRHH is a highly-integrated, low-power, complete analog monitoring and control system in a very small package.

For monitoring functions, the AMC7891 has 8 uncommitted inputs multiplexed into a 10-bit SAR analog-to-digital converter (ADC) and an accurate on-chip temperature sensor. Control signals are generated through four, independent, 10-bit digital-to-analog converters (DACs). Additional digital signal monitoring and control is accomplished through twelve configurable GPIOs. An internal reference can be used to drive the ADC and DACs.

Feature of AMC7891SRHH

10-Bit, 500-kSPS SAR ADC:

8 External Analog Inputs

VREF, 2 × VREF Input Ranges

Four 10-Bit Monotonic DACs:

0 to 5-V Output Range

Up to 10-mA Sink and Source Capability

Power-On Reset to 0 V

Internal 2.5-V Reference

Internal Temperature Sensor:

–40°C to +125°C Operation

Accuracy of ±2.5°C

12 General-Purpose I/O Ports:

1.8-V to 5.5-V Operation

Low-Power SPI-Compatible Serial Interface:

4-Wire Mode, 1.8-V to 5.5-V Operation

SCLK up to 30 MHz

Temperature Range: –40°C to +105°C

Low Power: 32.5 mW at 5 V, Full Operating Conditions

Space-Saving Package: 36-pin, 6-mm × 6-mm QFN

Applications of AMC7891SRHH

Cellular Base Stations

RF Communication Systems

Optical Networks

General-Purpose Monitor and C ontrol
