The ADRF5545ABCPZN is a dual-channel integrated radio frequency (RF) front-end multi-chip module designed for time division duplex (TDD) applications operating from 2.4 GHz to 4.2 GHz.

Product Type: RF Front End

Type: RF Front End

Operating frequency: 2.4 GHz to 4.2 GHz

NF-Noise factor: 1.45 dB

Operating supply voltage: 4.75 V to 5.25 V

Operating supply current: 86 mA

Maximum operating temperature: + 105 C

Mounting style: SMD/SMT

Package / Case: LFCSP-40

Development Kit: ADRF5545A-EVALZ

Gain: 32 dB

Minimum operating temperature: - 40 C

Humidity sensitivity: Yes

OIP3 - Third order cut-off point: 32 dBm

P1dB - Compression point: 19 dBm

Product Type: RF Front End

Factory Packed Quantity: 750

Sub Category: Wireless & RF Integrated Circuits

Technology: Si

Unit weight: 112 mg

Applications

Wireless Infrastructure

TDD large-scale multi-input and multi-output and active antenna systems

TDD based communication systems
