Trade Name:Data Acquisition - ADC/DAC - Special Purpose
Brand:ADI
Particular Year:24+
Package:BGA-81
Delivery Date:New and original
Stock: 3000pcs
The ADAQ4370-4BBCZ is a four-channel Precision Data Acquisition (DAQ) signal-chain μModule solution that shorens the development cycle of precision measurement systems by shifting the signal-chain design challenges of component selection, optimization, and layout from the designer to the device.
The ADAQ4370-4 uses system level Package (SIP) technology to integrate multiple common signal processing and conditioning modules into a single device, thereby reducing the number of end-system components. These modules include a four-channel, high-resolution 16-bit, 2 MSPS synchronously sampled SAR ADC, a low-noise, fully differential ADC driver amplifier, a 3.3V precision reference voltage source, a low-noise buffer amplifier, and a low-differential linear regulator.
Product Attributes:
Series: ADAQ4370-4
Installation style: SMD/SMT
Package/box: BGA-81
Product: Data Acquisition ADCs
Resolution: 16 bit
Number of channels: 4 channels
Supply voltage - Minimum: 4.5V
Power supply voltage - Max: 5.5V
Operating temperature: -40 °C to + 105°C
Package: Tray
Trademark: Analog Devices
DNL - differential nonlinearity: 0.6 LSB
Gain error: 0.01% FS
Inl-integral nonlinearity: 0.85 LSB
Interface type: Serial
Pd-power dissipation: 223 mW
Product Type: Data Acquisition ADCs/ DCS-Specialized
Reference voltage: 3.3V
Sampling ratio: 2 MS/s
Shutdown: Shutdown
SNR - Signal to Noise ratio: 97.5dB
